Water quality automatic sampler, Model HT-CYS-I

timed sampling

Collect water samples at set intervals and mix them in a mixing bucket

time-proportional

Collect water samples at regular intervals and mix them in a mixing bucket

traffic ratio

Collect water samples based on cumulative flow rate and mix them in a mixing bucket

Traffic tracking

Automatically adjust the sampling speed according to the flow rate and collect water samples into the mixing bucket

Trigger sampling

When receiving external trigger signals (switch signals), collect water samples into the mixing tank

Remote sampling

When receiving remote commands, perform sampling, sample supply, sample retention and other operations according to the command requirements

Synchronize sample retention

After the analyzer supplies the sample, retain the sample for comparison

Excessive retention of samples

Any monitoring factor that exceeds the standard will initiate the retention of samples, and the water sample will be collected into a retention bottle

Directly retain samples

The collected water sample is directly stored in a sample bottle

Remote sample retention

After receiving remote sample retention instructions, sample the quantitative water sample into the retention bottle

LCD screen

seven inch

System clock time control error

Δ  1≤0.1% Δ 12≤30s

Sample bottle retention

1000ml×24  bottle

Mean time between failures and continuous operation

≥ 1440h/time

Mixing bucket capacity

A  Bucket 5L, B bucket 5L

communication interface

RS-232、RS485

Single sampling quantity

1～5000ml  adjustable

Analog interface

five Road 4-20mA

sampling interval

1～9999min  adjustable

input interface

nine Road switch quantity

data recording

ten thousand article

output interface

one Road switch quantity

temperature control accuracy

4±2℃

ambient temperature

5℃~35℃

Sampling quantity error

±  10%

equipment power supply

AC（220±22）

Proportional sampling error

±  15%

Equipment power

300W

Sampling vertical height

≥8m

Dimensions (width * depth * height)

480mm×550mm×1460mm

Horizontal sampling distance

0～50m

Total weight

≤90Kg
