Water quality multi-parameter online monitor, Model HT-WCS-I

二维码

Products and Applications

Product Details

　　Product Overview

　　The water quality multi parameter online monitoring instrument can flexibly combine and select sensors according to user measurement needs, achieving real-time monitoring of multiple water quality parameters on a single machine.

　　Optional factors

　　PH、 Dissolved oxygen, conductivity, turbidity, suspended solids, temperature ORP、COD、 Ammonia nitrogen, nitrate, fluoride, chloride, chlorophyll, blue-green algae, oil in water, sludge concentration, liquid level, pressure, flow rate, flow rate, etc.

　　Product parameters

routineFive parameters
measurement parameters	measurement range	Measuring principle
PH	0~fourteen	Glass electrode method
dissolved oxygen	0~twenty mg/L	fluorescence method
conductivity	0~twenty0000uS/cm	Electrode method
turbidity	0~4000NTU	scattering method
temperature	0~55℃	Platinum thermal resistance method

optionalparameter
measurement parameters	measurement range	Measuring principle
ORP	-2000~2000mV	Platinum electrode method
COD	0~500mg/L 0~500NTU	UV254nm method 546nm Transmission method turbidity compensation
Ammonia nitrogen, chloride, fluoride	0~ten00mg/L	Ion selective electrode method
chlorophyll	0~500.0 ug/L (chlorophyll-a) 0~ten00ppb (Jordan Ming WT)	fluorescence method 460nm/680nm
blue-green algae	0~2,000 Kcells/mL	fluorescence method 590nm/650nm
oil in water	0~50/ten0ppm	fluorescence method 360nm/460nm
Sludge concentration	0~5/50g/L	scattering method

　　Performance indicators

Conventional five parameters
name	dissolved oxygen	pH	conductivity	turbidity	water temperature
repeatability error	±0.3mg/L	±zero point onepH	±1％	±5％	N/A
zero drift	±0.3 mg/L	N/A	±1％	±3％	N/A
range drift	±0.3 mg/L	N/A	±1％	±5％	N/A
drift	N/A	±zero point onepH	N/A	N/A	N/A
response time	2min	0.5min	0.5min	N/A	N/A
Temperature compensation accuracy	±0.3 mg/L	Within ± zero point onepH	±1％	N/A	N/A
measurement error	N/A	N/A	N/A	N/A	±0.5℃

optional parameter
name	ORP	COD	ammonia nitrogen	chlorophyll	blue-green algae
accuracy	±1mV	±7%	±10%	±5%	±5%
resolution	zero point one	zero point zero one	zero point zero one	zero point zero one/0.1	zero point zero one/0.1/1
Response time (s)	15	NC	15	10	10

other

Environmental requirements: Temperature 0～50℃； 10~90%RH

electricity Source: 100~240 V AC, 50 Hz ± 10%

Sensor protection level: IP65 Protection level

Communication: RS485 Modbus/HJ212 (supports customization)

Abnormal alarms and power outages will not result in data loss

Touch screen display and command input

Automatic restoration of working status after abnormal reset and power outage when power is restored

Customizable integration of various functions
