Product Overview
The full spectrum water quality analyzer utilizes full spectrum technology to capture the characteristics of substances in multiple spectral bands such as ultraviolet, visible, and near-infrared, establish mathematical models, invert substance content, and provide data support for water quality monitoring information management. It has the advantages of fast analysis, no reagent consumption, and accurate modeling. It can comprehensively perceive water quality and respond in the first time in case of water pollution accidents, achieving real-time monitoring and analysis of water quality.
Measurable factor
CODcr、CODmn、BOD、TOC、DOC、AOC、NO3-N、 Turbidity NO2-N、H2S、TSS、UV254、UVT、 chlorophyll a、 Chloramine O3、BTX、 Aniline, chromaticity, oil in water, temperature and pressure.
Product Features
▶ Multiple measurements with one meter, monitoring all factors ▶ Qualitative analysis, completed within tenseconds
▶ Simple operation and maintenance, long lifespan ▶ Fast analysis speed and traceable graph
▶ No pre-treatment required, no medication consumption ▶ Integrated optical measurement, supporting in-situ monitoring
Technical parameters
indicator name | Technical Specifications |
Measuring principle | Full spectrum measurement |
wavelength range | 190nm Up to 1100nm |
optical path measurement | 5，15，30mm optional |
light source | Xenon lamp light source, flashing 10times To the power of 9 |
knowledge graph | Characteristic spectral lines that can display factors |
measurement period | 10 second |
Protection level | IP66 |
material | Stainless steel 316; titanium alloy T1 optional |
wash | Probe configuration with automatic cleaning hole, maintenance free |
storage | 8G， Can store log data for many years |
sensor | Power supply voltage sensor, tilt sensor, rotation sensor |
Compensation: | Automatic compensation of turbidity, chromaticity, and water medium cross sensitivity for beam, optimizing measurement and diagnosis |
Range selection
surface water | sewage | |||
optical path measurement | 5mm | 30mm | 5mm | 30mm |
COD(mg/L) | 0 - 500 | 0 - 50 | 0 - 500 | 0 - 50 |
BOD(mg/L) | 0 - 300 | 0 - 40 | 0 - 300 | 0 - 40 |
TOC(mg/L) | 0 - 210 | 0 - 30 | 0 - 400 | 0 - 60 |
NO3- (mg/L) | 0 - 100 | 0 - 15 | 0 - 45 | 0 - 10 |
TSS(mg/L) | 0 - 1200 | 0 - 170 | 0 - 600 | 0 - 80 |
turbidity NTU | 0 - 1400 | 0 - 200 | 0 - 1200 | 0- 170 |
